Balcrank UP10 1" Diaphragm Pump 1120-044

UP10 1″ AODD Pump

The new Balcrank UP10 pump combines a Universal design with a unique frictionless Pivot-Shaft Air Valve to provide maximum performance and energy efficiency, exceeding market expectations.

UP10 Metallic pumps make the difference through:

• Higher Efficiency: Maximum fluid flow with reduced air consumption.
• Increased Reliability: No stall, no icing, reliable start-up, and longer air valve and diaphragm life.
• Maximum Versatility: Aluminum and Stainless Steel pumps with a wide range of diaphragms, seats, and balls options offer broad fluid and application compatibility. Highly suitable for outdoors and general applications with the presence of abrasives.
• Easy Servicing: Simplified maintenance and cleaning. The pump is held together by carriage bolts and nuts, allowing for a much faster tear down and rebuild.
• Connectivity: Can be configured to connect a Smart Pump-Controller System to actuate, control, and monitor your pumps.
• Compact Design: Designed for space-efficient operation.

Technical Data

• Pressure Ratio: 1:1
• Maximum Free Delivery: 53 US gal/min (200 l/min)
• Air Pressure Operating Range: 20 to 120 psi (1.5 to 8 bar)
• Max. size solids in suspension: 1/4" (6.4 mm)
• Maximum dry suction lift: 16' (5 m)
• Maximum wet suction lift: 26' (8 m)
• Displacement per cycle: 0.2 gal (0.85 l)
• Fluid inlet and outlet connections: 1" NPT (F) - Threaded
• Air inlet connection: 1/2" NPSM (F)
• Air exhaust connection: 1" NPT (F)
• Sound Level: 75 dB (A) @ 50 cycles/min @ 72 psi
• Weight (Aluminum): 25 lb (11.5 kg)
