SKU: SKU: TB CSM201
Prevost ALTO Micro Filter-Regulator with Wall Bracket - 2 Units - TB CSM
Prevost ALTO Micro Filter-Regulator with Wall Bracket - 2 Units - TB CSM
Couldn't load pickup availability
Local Service Available on All Brands
100% Secure Payment
Buy Now, Pay Later
Free Returns & Exchanges
ALTO Micro Filter-Regulator with Wall Bracket - 2 Units - TB CSM
The ALTO Micro Filter-Regulator with Wall Bracket - TB CSM is a two-unit compressed air preparation system featuring dual-stage filtration for applications requiring compressed air without oil contamination. Combining 5 µm and 0.01 µm filtration stages with pressure regulation, it helps remove fine particles and oil aerosols from the compressed air stream while controlling downstream air pressure. The unit is equipped with a pressure gauge featuring a glass dial and a 0–145 PSI measurement range. It has a specified maximum output pressure of 174 PSI and an operating temperature range of 41°F to 122°F. Available in 1/4" and 1/2" FNPT connection sizes, with flow rates of 9 and 53 CFM respectively, measured at 87 PSI with a 14 PSI pressure drop.
| Part Numbers | Female Thread (in) | Flow Rate (CFM at 87 PSI, ΔP = 14 PSI) | Max. Output Pressure | Filtration | Pressure Gauge Range | Temperature Min/Max |
|---|---|---|---|---|---|---|
| TB CSM201 | 1/4" FNPT | 9 CFM | 174 PSI | 5 µm / 0.01 µm | 0–145 PSI | 41 / 122 °F |
| TB CSM203 | 1/2" FNPT | 53 CFM | 174 PSI | 5 µm / 0.01 µm | 0–145 PSI | 41 / 122 °F |
