Chicago Pneumatic Combi Drill/Hammer - CP0009/CP0014RR Series
Chicago Pneumatic Combi Drill/Hammer - CP0009/CP0014RR Series
Couldn't load pickup availability
Local Service Available on All Brands
100% Secure Payment
Buy Now, Pay Later
Free Returns & Exchanges
CP0009 / CP0014RR – Combi Drills / Hammers
These versatile tools function as both a drill and a chipping hammer. A push of the rotation release button quickly converts the tool to hammer mode. Designed for a wide variety of construction and maintenance applications such as driving or setting masonry anchors and drilling holes in concrete, bricks, or rock. In hammer mode, they are ideal for chipping, scarifying, scaling, and cleaning welds.
General Overview
The CP0009 and CP0014RR rotary hammers deliver outstanding performance and durability. Their design ensures smooth operation, high power-to-weight ratio, and continuous lubrication through a built-in oiler. These tools are suited for professional use in demanding environments.
Key Specifications
- Excellent power-to-weight ratio for faster, easier drilling than electric rotary hammers
- Built-in oiler provides continuous lubrication
- Teasing throttle for precise control
- Rotation release button converts tool to hammer (except on CP0009AC)
- Cushioned piston for smooth operation and long life
- Muffler option available for noise reduction
Benefits
- Fast, efficient drilling in concrete, brick, and rock
- Easy conversion from drill to hammer mode
- Durable construction for long tool life
- Consistent performance under heavy-duty use
Model Details
CP0009
- Right-hand rotation
- Can use SDS Plus drill bits with adapter (R137586)
- Spline version available
- Accepts all electric steel
- Air consumption at 90 psi: 19 cfm
CP0014RR
- Superior drilling rates
- Greater drilling capacity vs. plug hole drills
- Designed for production drilling of small holes
- Air consumption at 90 psi: 47 cfm
Technical Specifications
| Model | Part No. | Net Weight (lb) | Air Inlet (in) | Overall Length (in) | Impact Rate (bpm) | Max Drilling Depth (in) | Chuck Type | Chuck Size (in) | Air Consumption (cfm @ 90 psi) |
|---|---|---|---|---|---|---|---|---|---|
| CP0009 A (with rotation release) | 8900002003 | 8.82 | 3/8 NPT | 14.75 | 3420 | 17.5 | Round shank | 3/4 × 3-3/4 | 19 |
| CP0009 AC* | 8900002008 | 8.82 | 3/8 NPT | 14.75 | 3420 | 17.5 | Round shank | 3/4 × 3-3/4 | 19 |
| CP0009 F (with rotation release) | 8900002004 | 8.82 | 3/8 NPT | 14.75 | 3420 | 17.5 | Spline drive | - | 19 |
| CP0009 CS | 8900002007 | 8.82 | 3/8 NPT | 14.75 | 3420 | 17.5 | BSP collared head/hose | - | 19 |
| CP0014 RR | 8900002010 | 14.77 | 3/8 NPT | 18.5 | 2520 | 25.5 | Spring hex shank | 7/8 × 3-1/4 | 47 |
*Use adapter R137586 with round-shank CP0009 units for SDS Plus electric hammer drill bits.
